Mockingbird RF Test System
PRODUCT OVERVIEW
As a RF signal processing and test engineer, you need a RF test system that enables agile test-driven development at the pace of your development. Mockingbird provides RF signal generation, spectral analysis and signal capture in a compact, rugged, software defined RF test system that enables rapid testing and verification of RF systems in the lab and in the field. Verify wireless data links, signal detectors and demodulators, and complex spectral sensing algorithms throughout your development cycle from design prototypes to outdoor Over-the-Air (OTA) testing. The simple and intuitive web interface enables collaborative testing and remote monitoring applications, and Mockingbird integrates with the tools you use today like Matlab and GNURadio.
KEY FEATURES
| Feature | Benefit |
|---|---|
| Waveform Toolkits | Direct emulation of specific signals “radio personalities” using configurable built-in waveform generators • CW Test Signals: Tone, Two-Tone, Stepped Freq, Sweep • Analog Modulation: AM, FM • Digital Modulation: • FSK (MFSK, GFSK, MSK, GMSK) • PSK (MPSK, OQPSK, PI/4 QPSK, DPSK) • QAM (QAM16, QAM64) • Frequency Hopper • OFDM |
| Arbitrary Waveform Generation | Import custom baseband I/Q waveforms from MATLAB and GNU Radio. |
| RF Scene Creation | Create realistic traffic patterns and mixtures of RF signals to create sophisticated RF scenes (i.e. emulated RF environments). |
| Spectrum Analyzer | Wideband dual-channel spectrum analyzer including Power Spectrum, and time-frequency falling raster with typical spectral analysis functions such as max hold, dual markers and peak search. |
| Spectrum Monitoring | Disjoint multi-band spectrum monitoring (e.g. 915 MHz ISM band and 2.4 GHz WiFi). Ability to create user configurable frequency scan lists. |
| Signal Capture | Capture narrowband and wideband signals up to 40 MHz BW, and 50 million complex baseband I/Q samples for detailed signal processing and analysis. |
| Network Attached Software Defined Instrument | Ethernet attached device with simple and intuitive web interface. No software installation required. Configure for your network and start testing immediately. Create multiple system deployments, for more sophisticated testing scenarios or multi-user access. Supports remote operation. |
SPECIFICATIONS
| RF Frequency Range | 50 MHz to 6 GHz (standard) (Lower and higher frequency options are available) |
| RF Channel Spacing | 2.4 Hz frequency tuning steps |
| Instantaneous Bandwidth | Up to 40 MHz |
| Transmit Power | -70 dBm to 20 dBm (gain steps of 0.25 dB) |
| Receiver Sensitivity | -105 dBm (typical) |
| Receiver Gain | 0 to 72 dB (gain steps of 1 dB) |
| Receiver Noise Figure | < 6 dB |
| RF Interfaces | 2x2 and 4x4 MIMO configurations N-type connectors (other options are available) |
| GPS Receiver | Internal commercial GPS N-type connector (other options are available) |
| Data Interfaces | Ethernet (10/100/1000) USB |
| Power Input | 24 VDC (External AC/DC power converter) |
| Dimensions | 6.75” x 8.5” x 3.5” (benchtop system) (multiple system rack mount configurations are available) |
| Weight | 4.35 lbs |
INTERESTED IN MOCKINGBIRD?
Syncopated is a creative provider of custom products and solutions for cognitive radio and edge analytic acceleration. Our solutions enable you to start further down the development path, reducing time-to-market and allowing you to focus on your innovative solution. Unlike most vendors, customization of our products for your specific needs is embraced not discouraged.
Our Mockingbird RF Test System is the perfect solution for agile test-driven development in and out of the lab. Contact us today for pricing and customization details.
